Victoria 20Little Victoria, Optimise your space

Small budget lodge with 2 bedrooms
Can accommodate a family of 4 to 6 people

All the qualities of a lodge, made smaller

The Victoria 20 has the same indoor space (20m², 5 x 4m) as the Victoria 30, with 2 spacious bedrooms and a corner kitchenette. It is the perfect solution for smaller plots, offering he same comfort at a lower price.

As an optional extra, this lodge can come with an independent terrace, protected by a canvas shade.

The finest materials

With a 40x2mm zinc-plated steel structure with a rust-effect finish, reinforced with braces and water-repellent bars and finished with a Ferrari PVC canvas secured with stainless steel pawls, the Victoria 20 is a Lodge built with quality in mind.

It can stay up all year round (except in regions with heavy snowfall), and the height of the pilotis can be adjusted from 18 to 92cm, ensuring that the floor can adapt to all kinds of terrain without any deterioration.

Our 2, 3 or 4-step staircases can be installed at the front or the side of the lodge.

General characteristics
Surface du Lodge 5,00 x 4,00 m (20 m²)
Number of people 4 to 6
Number of bedrooms 2 (2,35 x 2,00 m)
Mosquito netting and windows 1 indoor shutter in each bedroom + mosquito netting
2 outdoor shutters on the front gable + mosquito netting
2 indoor shutters in the living room + mosquito netting
Structure
Frame  Galvanised steel and rust-brown polyester paint, diameter 40x2mm
2 wooden posts in Class 4 autoclave-treated pine,
90x90mm + galvanised steel connectors and rust-brown polyester paint
Optional railing Railing with BATYLINE FERRARI grill protection
Canvas
Interior canvas Polyester velum 280g/m²
Exterior canvas, wall and gable 580g/m² coated PVC – Pre-stressed FERRARI M2
Roof canvas 580g/m² coated PVC – Pre-stressed FERRARI M2
Canvas tightening On the ground, using rings and rails
Roof-frame attachment system Stainless steel ratchet straps
Facade  Removable façade with door, zip closing. Padlock locking (not included)
Terrace siding (optional) PVC 630g/m² – M2 Ferrari
Ground-level terrace with canvas shade
Ground-level flooring (4.54 x 2.45m) 11.12m²
Made from 27 x 145mm wooden planks,
Class 4 autoclave-treated according to European standards, sourced from certified Scandinavian forests
95 x 45mm strips and 120 x 45mm cross ties, under-floor tarpaulin to prevent plant growth,
stainless steel screw fittings
SOLTIS 86 micro-aerated canvas shade – 380g/m²
Mounted on four Class 4 autoclave-treated pine logs, 80mm diameter
Galvanised steel post supports and rust-brown polyester paint finish
Foot reinforcement plates in galvanised steel
Flooring
Piloti-mounted flooring 4,64 x 5,36 (24,87 m²) – 16 poles
Flooring can be adjusted from 18 to 92cm to adapt to the terrain
Wooden planks 27 x 145mm, sourced from certified Scandinavian forests
Class 4 autoclave-treated according to European standards
Fitted with sixteen 90 x 90mm posts 95 x 45mm strips and 120 x 45mm cross ties,
Under-floor tarpaulin to exclude draughts
Stainless steel screw fittings
Adjustable pilings from 18 to 92 cm
1 to 4-step staircase
Installation on gravel-covered slabs

Download the brochure of Lodge Victoria 20
